Enhance your electronic projects with the WH2004H-TFH-JW# – Winstar alphanumeric LCD display, designed for superior readability and performance. Featuring a 20×4 character layout, this display delivers crisp black content on a white background, ensuring clarity from a 6:00 viewing direction. Built with FSTN Positive LCD technology and a transfective polarizer, the WH2004H-TFH-JW excels in varied lighting conditions, offering versatility across applications. Its robust module type, COB – Chip on Board, ensures durability, while the ST7066 controller guarantees seamless integration with a 6800 interface. With an active area of 70.4×20.8mm and compact dimensions, it's perfect for space-constrained projects. Operating efficiently between -20°C and 70°C, and storing safely from -30°C to 80°C, the WH2004H-TFH-JW provides reliable performance in diverse environments. Choose this Winstar display for its exceptional quality and multilingual font support, including English, European, and Japanese.
| Characters x Rows | 20x4 |
|---|---|
| Content Color | Black |
| Background Color | White |
| Viewing Direction | 6:00 |
| Module type | COB - Chip on Board |
| LCD Type | FSTN Positive |
| Polarizer Type | Transflective |
| Interface | 6800 |
| Controller | ST7066 |
| Fonts | English, European, Japanese |
| Active area (mm) | 70.4x20.8 |
| Outline Dimensions (mm) | 98.0x60.0x13.6 |
| Operating temp. (°C) | -20~70 |
| Storage temp. (°C) | -30~80 |
| Special | |
| Manufacturer | Winstar |
This module can operate in a stable and failure-free way for a long period within wide range of temperatures. Thanks to such option, it may be successfully applied e.g. in transportation and automotive industry.
