DMG48320C035_03WN DWIN 3.5″ 320×480 Smart LCD-TFT display

The DMG48320C035_03WN is a versatile 3.5′ smart LCD-TFT display with a crisp 320×480 resolution. Powered by DWIN’s T5L1 ASIC and running the DGUS II HMI platform, it offers smooth UI performance and easy integration. With full viewing angles, industrial temperature range, and UART interface, this compact display is ideal for various applications. The DMG48320C035_03WN combines reliability and functionality in a sleek 61.1×103.3×10.5mm package.

Datasheet

Ask our team for:

Size (inch)3.5
Resolution320x480
Aspect ratio16:9
Brightness (cd/m²)300
Viewing DirectionFull
InterfaceUART
ControllerT5L1
Active area (mm)49.00x73.40
Outline Dimensions (mm)61.1x103.3x10.5
Operating temp. (°C)-20~70
Storage temp. (°C)-30~80
ManufacturerDWIN

Need a display for the designed device?

Contact our experts – we’ll help you choose the optimal solution adapted to your needs.

Industrial operating temperature range


This module can operate in a stable and failure-free way for a long period within wide range of temperatures. Thanks to such option, it may be successfully applied e.g. in transportation and automotive industry.

Full observation angles

Full observation angles

Using an IPS/MVA (or a variation thereof) matrix, the display is readable from all angles. There is no grayscale inversion effect that characterizes popular TN matrices. Also, the decrease in contrast when increasing the viewing angle is much lower.
